NC528XC Security Camera
Security Camera
- 5MP
- Motorised Zoom
- 80 IR Distance
- Bullet
- IP66
Product Overview
Features
Engineered for reliable protection, NC528XC Security Camera combines advanced imaging and intelligent analytics to deliver smarter security.
Crystal Clear Clarity
High resolution ensures every detail is captured with precision, for the ultimate surveillance experience.
Capture the Moment
Incredible speed, providing you with smooth and seamless footage. Never miss a moment.
Cater to your surveillance needs
Device configuration tool enables seamless maintenance and allows searching the network for IVSEC devices.
Monitor & Update Remotely
View live camera footage, receive alerts on-the-go, schedule alarms and more with the iVSEC App.
Full Vivid Colour
Advanced Features with Vibrant Color and High-Quality Imaging at Night.
Value AI
Complete protection with accurate and targeted alerts to potential threats & reducing false alarms.
Professional AI
Now capable of processing Advanced Al features, thanks to the inclusion of a specifically designed Al Chipset.
Made to Withstand the Elements
With a metal casing, IP66 provides weatherproof monitoring & incredible durability.
Technical Specifications
| Camera Type | Bullet |
| Image Sensor | 1/2.7″ Progressive CMOS |
| Maximum Video Resolution (Megapixels) | 5 |
| Maximum Video Resolution | 2592 x 1944 |
| Lens | 5-50 mm (H.FOV: 50.9 to 7.6°) |
| Lens Type | Motorised Zoom |
| Maximum Night IR Distance (M) | 80 |
| Video Compression | H.265+, H.265, H.264+, H.264, MJPEG |
| ONVIF depends on firmware version | ONVIF( Profile S/G/T) 21.12 or greater, Http API |
| IP Rating | IP66 |
| Operating Environment | -10ºC to 55ºC (14ºF-131ºF) Humidity: 20%-80% RH |
| Dimensions | Ø108 X 301mm |
| Weight | 1.468 |
| Accessories | IV2422X |
| Power Supply | Power over Ethernet IEEE 802.3af, DC12V |
| Power Consumption | <10W |
| Connectors | RJ-45 , DC Power Input, Analog Video Output, Audio In, Audio Out, Alarm in or out *4, reset button |
| Outdoor Use | Yes |
| IP Rating | IP66 |
| Vandal Resistant | Yes |
| Frame Rate at Resolution | 25 |
| Day/Night Mode | Auto |
| Image Enhancement | Flip mode, Brightness, Contrast, Saturation, Sharpness, Hue, Corridor Mode, Mirror, Angle Flip, Back Light, White Balance, Shutter, Time Exposure, Defog, 3D Noise Reduction |
| Edge Recording microSD/SDHC Card | Micro SD/SDHC Card |
| Multiple Streams (encode format) | 3 Streams |
| Audio Streaming | Yes – input connector for external mic |
| Protocols | TCP/IP, UDP, HTTP, HTTPS, DHCP, FTP, RTP/RTSP, DNS, DDNS, NTP, PPPOE, UPNP, SMTP, SNMP, P2P (QR code) |
| Intelligent Video (IVS) | IVS such as Perimeter Detection, Face Recognition, Human & Vehicle Detection, Line Crossing Detection, Stationary Object Detection, Crossing Counting, Heat Map, Crowd Density Detection, Queue Length Detection, License Plate Detection, Rare sound detection |
| Cloud option (camera only) | Dropbox |
| Software | Device Search/Config Tool, Surveillance Client (CMS/VMS), Mobile app (QR code) |
| Power Over Ethernet | Yes |
| Ethernet | Ethernet (10/100 Base-T) |
| In The Box | Free Software available from FTP, Printed quick user guide, installation template, mounting screws & plugs |
| Warranty | 3 Year Warranty |
